Description
Item specifics
Brand Name: Olysine
Alarm Type: Rear Side,Accessories,Vehicle Backup Cameras
Wire or Wireless: Wire
Material Type: Abs
Shell Material: Plastic
Length of Video Cable: 6M
Lens Material: Plastic + Glass
Guiding Line: Yes
Color: Black
Camera: Night Vision Camera
Product Description
dianxiaobao_1
dianxiaobao_2
8 Infrared Lamp Back Camera
Real IR Night Vision
8 Infrared Lamp, Real Night Vision, can work in full dark environment, not Ordinary LED
CCD Chipset
with the CCD video processing chip, the performance of the rearview camera is reliable and stable, image and color
reproduction has further improved. image is clear, reversing more safely.
HD Reverse image
140deg Large Wide Angle
Waterproof
Install effect
Testing
In Room
Full Dark Environment
Outdoor
Installation
Feature:
1.Anti fog glass.
2.CMOS imaging sensor.
3.Support NTSC&PAL video system.
4.Snap-in design, it is easy to install.
5.High sensitivity and low power consumption.
6.Water-proof, shock-proof and anti-jamming functions.
7.It helps to avoid incidents and accidents abrasion well.
8.Extra-low illumination of 0.5 Lux for clear night vision.
9.Its simple and modest design and small size won t draw any attention.
10.This camera can give you a full sight of the back of your car when you are driving.
11.To protect your car from collision with invisible obstacle, choose a high definition and good quality camera as ours.
12.Perfect solution to get rid of that poor rear view visibility on your car that has no rear-view mirror or poor rear vision.
Specifications:
Pixels: 656(H) * 492(V)
Video output 1.0VP-P, 75 OHM
Scanning system 2: 1 interlace
Operating temperature -20 deg ~ + 75 deg, RH95% MAX
Storage temperature -40 deg C to 85 deg C, RH 95% MAX
TV system PAL / NTSC
Light perception area of 3.584mm * 2.688mm
Gamma coefficient 0.45
Lens angle lens angle: Level: 135deg / Diagonal 170deg
Horizontal clarity 480 TV lines
Shutter speed 1-1 / 10000
White balance auto
Waterproof grade IP67 / 68
Power supply DC 12V
dianxiaobao_3
dianxiaobao_4
Packaging Details
Unit Type: Set
Package Weight: 0.15kg (0.33lb.)
Package Size: 12cm x 8cm x 5cm (4.72in x 3.15in x 1.97in)
